HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners Wholesale

Home / Products / Voltage Protector / US Standard Voltage Protector / HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners
HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners

HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners

  • HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners
  • HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners
  • HWTB-V004-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners
Request Quote
PREV：HWTB-V013-US 120V 10A Automatic Voltage Surge ProtectorNEXT：HWTB-V003-US 110V 30A US Adjustable Voltage Protector For Air Conditioners
  • Product Parameters
  • Contact Us

Designed for 230V/50Hz power grid environments, this product offers a rated output of 30A/6900W, making it one of the models with the highest power density in the entire series. To adapt to complex international power standards, its parameters are extremely finely adjustable: the delay time is adjustable from 180-300 seconds, and both the undervoltage protection point (165V-205V) and overvoltage point (230V-260V) are manually set. The one-button ON/OFF design on the front panel is highly user-friendly. With optional 125J surge protection and high-quality relays, the product ensures stable operation of high-power industrial air conditioners or single-phase loads in three-phase power environments, even in harsh power grid conditions.

Safety and performance specifications: Flame retardant V0 and pure copper conductor



Operating Voltage

 230V

Wait Time

 180-300s (Adjustable)

Frequency

 50/60Hz

Power

 30A/6900W

Undervoltage

 165V-205V (Adjustable)

Overvoltage

 230-260V (Adjustable)

Surge

 125J (Optional)

Warranty

 1 Year
