This product's core focus is on high-power output (30A/3300W) for 110V/60Hz systems. In addition to supporting an adjustable start-up delay of 180-300 seconds, this model also features a convenient one-touch ON/OFF button for quick power reset without unplugging. The internal structure is optimized for high-current loads, employing highly conductive thick copper components and a microprocessor to ensure accurate operation within an adjustable fluctuation range of 90V-145V. It's the perfect partner for protecting high-power refrigeration compressors, filtering instantaneous spikes through an optional 125J surge module. It not only meets the needs of everyday household air conditioners but is also suitable for protecting high-power equipment in commercial kitchens and laboratories, offering a one-year warranty.

Safety and performance specifications: Flame retardant V0 and pure copper conductor



Operating Voltage

 110V

Wait Time

 180-300s (Adjustable)

Frequency

 60Hz

Power

 30A/3300W

Undervoltage

 90V-115V (Adjustable)

Overvoltage

 125-145V (Adjustable)

Surge

 125J (Optional)

Warranty

 1 year
