HWTB-V041-CE 230V 30A US Adjustable Voltage Protector For Air Conditioners

The HWTB-V041-CE boasts an exceptional 30A/6900W output capacity. It is a core device for ensuring electrical safety in large-capacity air conditioners, central refrigeration systems, and multi-fan arrays.

In terms of technical construction and specifications, this model supports a wide adjustable wait time of 5-255 seconds, allowing users to set the optimal start-up interval based on compressor size. Voltage monitoring is extremely flexible: both undervoltage (165V-205V) and overvoltage (240V-260V) can be fine-tuned according to actual load voltage drop. The internal relays utilize specially enhanced contacts, coupled with thickened copper busbars, ensuring extremely low temperature rise even under a 6900W load.

Its industrial-grade microprocessor algorithm is optimized for handling high instantaneous starting currents, preventing false tripping. Optional 125J surge protection provides additional shock protection.

Safety and performance specifications: Flame retardant V0 and pure copper conductor
