READ MOREThe HWTB-V055UN-A-CE is a high-end universal socket protector with full-parameter digital adjustment capabilities under a 3300W load. It was developed to meet the needs of simultaneous protection for multiple standard devices in complex global power grid environments.
In terms of technical construction and parameter characteristics, this product supports an ultra-wide range of 5-999 seconds of delay-start adjustment. Users can precisely set protection within the 150V-210V undervoltage and 230V-280V overvoltage ranges via a digital display interface. The microprocessor has an extremely high sampling frequency, effectively identifying any minute fluctuations in 50/60Hz systems. The internal structure uses carefully selected copper materials and reinforced relays, and the optional 125J surge protection module further enhances the physical survival rate in the face of extreme surges.
This model is compatible with televisions, printers, computers, refrigerators, and air conditioners. The digital display screen ensures visual operation.
Safety and performance specifications: Flame retardant V0 and pure copper conductor
|
Operating Voltage |
230V |
|
Wait Time |
5-999-300s (Adjustable) Default-5s |
|
Frequency |
50/60Hz |
|
Power |
15A/3300W |
|
Undervoltage |
150V-210V (Adjustable) Default-198V |
|
Overvoltage |
230-280V (Adjustable) Default-255V |
|
Surge |
125J (Optional) |
|
Warranty |
1 year |
